AMD Ryzen 9 9950X3D2 Dual Edition 4.3 GHz 16-Core AMD AM5 Processor

AMD Ryzen 9 9950X3D2 Dual Edition

The AMD Ryzen 9 9950X3D2 Dual Edition 4.3 GHz 16-Core AM5 Processor is a CPU designed for AM5 motherboards that instills confidence in your gaming rig's ability to tackle the newest, most graphically intense games and keep a stable framerate.

The 9950X3D2 now features Dual AMD 3D V-Cache technology. This technology is specifically designed to promote high levels of gaming performance by placing the 16 cores and the 192MB of L3 cache close together. Add the 16MB of L2 cache and this CPU has a 208MB total cache. 208MB of cache means more game data, assets, and working data to sit right next to the CPU cores, which reduces latency and provides responsiveness across demanding workflows.

This CPU continues the trend of building upon the stable Zen 5 architecture, but what separates the 9950X3D2 is the 32-thread processing, 4.3 GHz base clock speed, and 5.6 GHz max boosted clock speed. AMD has also unlocked the CPU to make overclocking easier than ever. Connectivity isn't an issue for this CPU either as there is support for NVME, native USB 4, USB 3.2, and PCIe 5.0, so high-end graphics cards, SSDs, and up to 256GB of DDR5-5600 memory can be connected without worry. Integrated AMD Radeon graphics has also been built into the 9950X3D which allows you to do basic tasks and troubleshooting without the presence of a graphics card in your system.

AMD EXPO

Ryzen-optimized AMD EXPO (Extended Profiles for Overclocking) profiles provide a user-friendly method to overlocking your DDR5 memory when using the Ryzen 9 9950X3D2 with your socket AM5, increasing software load speeds and boosting overall gaming performance.

Precision Boost 2

AMD Ryzen processors monitor the system's energy consumption, temperatures, and other factors to automatically raise clock speeds, allowing applications to perform faster.

What are the benefits of AMD Ryzen 9 9950X3D2 Processor ?

• 16 Cores & 32 Threads

• AM5 CPU Socket

• 16MB L2 & 192MB L3 Cache

• Integrated AMD Radeon Graphics

• DDR5-5600 Memory

• Fully Enabled Overclocking

• Dual AMD 3D V-Cache Technology

• Zen 5 Architecture

General

CPU Model

AMD Ryzen 9 9950X3D2

CPU Socket

AM5

Manufacturing Process

4 nm

Maximum Number of PCIe Lanes

28 (Revision 5.0)

Unlocked

Yes

Performance

Number of Cores

16

Number of Threads

32

Base Clock Speed

4.3 GHz

Maximum Boost Speed

5.6 GHz

Dedicated AI Cores

No

L3 Cache

192 MB

Memory Support

Maximum Capacity

256 GB

Memory Support

DDR5 Up to 5600 MT/s

ECC Memory

Yes

Channel Architecture

Dual Channel

Power

Thermal Design Power (TDP, Max)

200 W

Included Thermal Solution

No

Maximum Temperature

203°F / 95°C

Thermal Monitoring Technologies

No

Technology

AES Support

Yes

Extension

AVX, AVX 2.0, AVX-512, FMA3, SSE 4.1

Instruction Set

64-Bit

Virtualization

Yes: AMD-V

Performance Technologies

AMD EXPO, Precision Boost 2

Integrated Graphics

Integrated Graphics

AMD Radeon

Output Support

DisplayPort
