TP-Link BE14000 Tri-Band Whole Home Mesh Wi-Fi 7 System

8-Stream 14 Gbps Tri-Band WiFi

8647 Mbps (6 GHz) + 4324 Mbps (5 GHz) + 688 Mbps (2.4 GHz).

Unprecedented 10 Gbps Network

1× 10 Gbps WAN/LAN port + 1× 2.5 Gbps WAN/LAN port + 1× 1.0 Gbps port ensure max flexibility and boosted throughput.

Wireless and Wired Combined Backhaul

Connects a wireless and wired backhaul with each unit simultaneously to improve overall throughput and reduce latency.

Multi-Link Operation (MLO)

Simultaneously send and receive data across different bands and channels to increase throughput, reduce latency, and improve reliability.

320 MHz Channels

Double the bandwidth and enables many more simultaneous transmissions at the fastest possible speeds.

Works on the 6 GHz Band

Minimizes congestion with greenfield spectrum, delivering robust high-speed connections.

TP-Link HomeShield

Provides comprehensive network protection, robust parental controls, and real-time IoT security.

Universal Compatibility

Backward compatible with all Wi-Fi generations and works with any internet service provider (ISP) and modem.

What are the benefits of TP-Link BE14000 Mesh ?

• Tri-band Wi-Fi 7 delivers ultra-fast speeds up to 14 Gbps

• 10 Gbps and 2.5 Gbps ports support high-speed wired connections

• Hybrid wired and wireless backhaul improves performance and reduces latency

• Multi-Link Operation (MLO) boosts speed, stability, and reliability

• 320 MHz channels maximize bandwidth for faster data transfer

• 6 GHz band reduces congestion for smoother connectivity

• TP-Link HomeShield provides advanced network security and parental controls

WIRELESS

Standards and Protocols

Wi-Fi 7

IEEE 802.11be/ax 6 GHz

IEEE 802.11be/ax/ac/n/a 5 GHz

IEEE 802.11be/ax/n/b/g 2.4 GHz

WiFi Speeds

BE14000

6 GHz: 8647 Mbps (802.11be)

5 GHz: 4324 Mbps (802.11be)

2.4 GHz: 688 Mbps (802.11be)

WiFi Range

Broader Whole Home Coverage

TP-Link Mesh Technology

Optional Ethernet backhaul work together to link Deco units to provide seamless coverage

AI-Driven Mesh

Intelligently learns the network environment to provide ideal Wi-Fi unique to your home

8× High-Gain Antennas (Internal)

Multiple antennas form a signal-boosting array to cover more directions and large areas

Tri-Band

The greenfield 6 GHz band brings more bandwidth and faster speeds

Working Modes

Router Mode

Access Point Mode

SOFTWARE

Advanced Features

Reboot Schedule

Tapo/Kasa Onboarding

IoT network & Device Isolation

Static Route Function

Node/Band Connection Preference

Protocols

IPv4

IPv6
