Industry-Leading Hardware Design

Equipped with an advanced design and the latest chipset, OC200 has enough processing power to support the massive management of your business network.

Wi-Fi Heatmap Simulator

Generate a Wi-Fi solution by simulating the wireless coverage effect of APs in the actual site. Determine the appropriate number and location of APs according to the coverage requirements.

Greater Convenience with the Omada App

Remotely access and configure your whole network with a tap of your phone from anywhere in the world.

Interface

2 × 10/100Mbps Ethernet Port

1 × USB 2.0 Port for configuration backup

1 × Micro USB Port for power

Power Supply

802.3af/at PoE or Micro USB（DC 5V/1A）

Omada App

Yes

Centralized Management

Up to 100 Omada access points, switches, and routers

Cloud Access

Yes

L3 Management

Yes

Multi-site Management

Yes

Management Features

Automatic device discovery

Batch configuration

Batch firmware upgrading

Intelligent network monitoring

Event logs and notifications

Unified configuration

Reboot schedule

Captive portal authentication

Certification

FCC, RoHS

System Requirements

Internet

Environment

Operating Temperature: 0℃~40℃ (32℉~104℉)

Storage Temperature: -40℃~70℃ (-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
